| Brand Name: | KINGRAIL |
| Model Number: | KP-5T |
| MOQ: | 1pc |
| Price: | negotiable |
| Packaging Details: | export packzge |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Features of Unpowered rail car trolley propelled or pulled by manual or other external forces
KP series unpowered rail car, also known as "rail trailer", "rail trolley", "rail trolley", is generally used in the occasion of small load and short-distance transportation of materials. Railcars that are pushed or pulled by artificial or other external forces.
KP series unpowered rail cars can be installed with traction lugs, hand-push handrails and other devices according to the requirements of users.
According to the user's requirements, other process devices can be installed on the table top of the KP series unpowered rail car, or the table top of the car can be deformed and improved according to the user's needs.
The color of the car body can also be sprayed according to the user's requirements.
This kind of rail trailer equipment includes a trailer body, the top of the trailer body is provided with a fixed plate A and a fixed plate B, the fixed plate A is located at the right part of the fixed plate B, the left end of the fixed plate A is provided with a groove A, and the fixed plate A is The front end is provided with a through groove, the left part of the fixed plate A is provided with a rotating plate, the interior of the through groove is provided with a rotating rod, the middle part of the rotating rod is provided with a clamping block, the left end of the rotating plate is provided with a groove B, and the two rotating plates are provided with a groove B. A telescopic plate is arranged between the two sides, a fixed box is arranged at the front end of the trailer body, a transmission rod in the middle of the fixed box, the left and right ends of the transmission rod are provided with bevel gears A, and the front ends of the two rotating rods are provided with bevel gears B. The rotating rod can drive the rotating plate to rotate, the left and right sides of the telescopic plate are elongated, and the two rotating plates and the telescopic plate are concave downward, which makes the device convenient for handling various parts.
| Unpowered rail car trolley propelled or pulled by manual or other external forces | ||||||||||||||
| Flat car model | KPX-2t | KPX-5t | KPX-10t | KPX-16t | KPX-20t | KPX-25t | KPX-30t | KPX-40t | KPX-50t | KPX-63t | KPX-80t | KPX-100t | KPX-150t | |
| Rated load capacity (t) | 2 | 5 | 10 | 16 | 20 | 25 | 30 | 40 | 50 | 63 | 80 | 100 | 150 | |
| Table size (mm) |
long(L) | 2000 | 3500 | 3600 | 4000 | 4000 | 4500 | 4500 | 5000 | 5500 | 5600 | 6000 | 6500 | 10000 |
| width(W) | 1500 | 2000 | 2000 | 2000 | 2200 | 2200 | 2200 | 2400 | 2400 | 2400 | 2600 | 2800 | 3000 | |
| high(H) | 150 | 500 | 500 | 550 | 550 | 600 | 600 | 650 | 650 | 700 | 800 | 900 | 1200 | |
| wheelbase(mm) | 1200 | 2500 | 2600 | 2800 | 2800 | 3200 | 3200 | 3800 | 4200 | 4300 | 4700 | 4900 | 7000 | |
| Inside distance of rail(mm) | 1200 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1800 | 2000 | 2000 | |
| Wheel diameter(mm) | Φ270 | Φ300 | Φ300 | Φ350 | Φ350 | Φ400 | Φ400 | Φ500 | Φ500 | Φ600 | Φ600 | Φ600 | Φ600 | |
| Number of wheels (pcs) | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 8 | |
| Ground clearance(mm) | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 75 | 75 | 75 | 75 | |
| running speed(m/min) | 0-25 | 0-25 | 0-25 | 0-20 | 0-20 | 0-20 | 0=20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-18 | |
| Motor Power(kw) | 1 | 1.2 | 1.6 | 2 | 2.2 | 3 | 3.5 | 4 | 5 | 6.3 | 8 | 10 | 15 | |
| Battery capacity(Ah) | 180 | 180 | 160 | 180 | 180 | 250 | 250 | 300 | 330 | 400 | 400 | 440 | 600 | |
| battery voltage(V) | 24 | 36 | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 48 | 72 | 72 | 72 | |
| Full load continuous running time | 4.32 | 5.4 | 4.8 | 4.3 | 4 | 4 | 3.5 | 3.6 | 3.3 | 3 | 3.6 | 3.2 | 2.9 | |
| recharge mileage(km) | 6.5 | 8.1 | 7.2 | 5.1 | 4.8 | 4.8 | 4.2 | 4.3 | 4 | 3.6 | 4.3 | 3.8 | 3.2 | |
| ***Large wheel pressure(KN) | 14.4 | 25.8 | 42.6 | 64.5 | 77.7 | 94.5 | 110.4 | 142.8 | 174 | 221.4 | 278.4 | 343.8 | 265.2 | |
| reference weight(t) | 2.8 | 3.6 | 4.2 | 5.5 | 5.9 | 6.5 | 6.8 | 7.6 | 8 | 10.8 | 12.8 | 14.6 | 26.8 | |
| Recommended rail model | P15 | P18 | P18 | P24 | P24 | P38 | P38 | P43 | P43 | P50 | P50 | QU100 | QU100 | |
| Description: 1. Load capacity, table size, rail inner distance can be designed and manufactured according to customer needs; 2. Optional wireless remote control device (domestic or imported); 3. Optional automatic stop when encountering people, limit limit device; 4. Optional maintenance-free battery, lithium battery, explosion-proof battery, high temperature battery, etc.; 5. Optional DC brush motor, DC brushless motor; 6. Optional domestic electrical appliances, imported electrical appliances. |
||||||||||||||
Manufacturer strength of Unpowered rail car trolley propelled or pulled by manual or other external forces
|
